Healthcare AI GYM for Medical Agents

Abstract

Clinical reasoning demands multi-step interactions — gathering patient history, ordering tests, interpreting results, and making safe treatment decisions — yet no unified environment exists to train generalizable medical AI agents through reinforcement learning. We present a comprehensive empirical study of multi-turn agentic RL for medical AI, built on Healthcare AI GYM, a Gymnasium-compatible environment spanning 10 clinical domains with 3.6K+ tasks and domain-specific tools.

Our analysis reveals three compounding pathologies absent from single-turn settings: response explosion, multi-turn collapse into verbose monologues, and distillation instability — all stemming from the misalignment of sparse terminal rewards with sequential clinical trajectories. To stabilize training, we propose Turn-Level Truncated On-Policy Distillation (TT-OPD), a self-distillation framework where a gradient-free EMA teacher provides dense, outcome-aware KL regularization at every conversation turn — achieving accuracy comparable to vanilla GRPO with controlled response length and sustained tool use. We further identify a fundamental agentic–textual transfer gap: RL improves procedural competence but does not transfer to text-based QA benchmarks. The environment, training pipeline, and all experimental artifacts are publicly available.

How it works

The overall workflow, step by step

Healthcare AI GYM closes the loop between a clinical agent, a Gymnasium environment, a tool & knowledge ecosystem, and a reward-driven RL trainer. Press Play to watch a single training episode flow through the system — each step highlights one component and explains what it does.

01 reset()

Patient case is loaded

The environment samples a clinical task and returns the first observation — a patient scenario plus the available tool menu — to the agent.

Contributions

Five contributions

01

Multi-Domain Medical Gymnasium

A Gymnasium-compatible environment: 10 clinical domains, 3.6K+ tasks, 135 domain-specific tools, an 828K-passage knowledge base, and a safety-aware 5D reward.

02

Systematic RL Benchmark

A rigorous comparison of GRPO, DAPO, Dr. GRPO and GSPO that exposes the trade-off between peak accuracy (62.0%) and training stability.

03

TT-OPD Framework

Outcome-aware regularization: correctness signals are injected into the teacher's context but withheld from the student, giving dense turn-by-turn guidance with controlled response length.

04

Systematic OPD Failure Analysis

Ablations trace the failure progression — KL collapse → response explosion — and identify multi-turn collapse as an agentic-specific failure mode absent from single-turn OPD.

05

Transfer Gap Analysis

RL-driven procedural competence (+22% composite reward) does not automatically translate to text QA, due to a 51:1 format-reward dilution ratio.

The environment

Inside Healthcare AI GYM

10 Clinical Domains

135 Tools · 4 types

Evidence RetrievalBM25 over 828K passages
Clinical Assessment22 validated scores — SOFA, NEWS, PHQ-9…
Intervention Actionslabs, imaging, prescribing, triage
Reasoning Scaffoldsdifferential dx, planning, ICD-10

828K-Passage Knowledge Base

PubMed abstracts, clinical guidelines (AHA, ACOG, SSC) and textbooks, indexed via BM25 and exposed as tool calls. Built on Self-BioRAG and OLAPH.

Safety-Aware 5D Reward

R = w·Acc + w·Proc + w·Safe + w·Fmt + w·Coh

A critical safety violation caps the composite score at 0.1 — directly countering format-reward dilution. An optional assertion dimension (0.15) is added when rubric annotations exist.

Method

TT-OPD: stabilizing multi-turn agentic RL

On-policy distillation collapses in agentic settings because the teacher goes stale as the student explores. TT-OPD keeps a gradient-free EMA teacher and feeds it outcome-aware hints that the student never sees — turning sparse terminal rewards into dense, per-turn guidance. Press Play to walk through one optimization step.

01 rollout

Student rollout

For each prompt, the student samples n = 3 multi-turn trajectories — interleaving think, search and submit actions in the GYM.

θ_T

Gradient-free EMA teacher

θ_T ← 0.995·θ_T + 0.005·θ_S, updated every 5 steps with a hard-copy fallback every 30 — the teacher tracks the student without ever taking a gradient.

h(τ)

Outcome-conditioned hints

Correct trajectories get confirmatory cues, incorrect ones get corrective redirection. Hints enter the teacher's context but are removed from its logprobs — the student never sees them.

R_cos

Cosine length control

Concise correct answers are rewarded most; reward decays with length and incorrect answers are penalized more as they grow — preventing monotonic explosion toward L_max.

Self-distillation is fragile: three failure modes

Distillation is most valuable early (steps 1–40) and should be monotonically phased out — not adaptively toggled. Each run dies a different death.

v29

Teacher corruption cascade

Unconditional EMA absorbs corrupted student weights; once KL > 0.7 a positive feedback loop collapses accuracy to 0%.

death @ step 70 · 10 steps

v30

Frozen teacher gap cascade

A static distill coef (4.0) is 10–20× the RL gradient; when the frozen teacher goes stale it overwhelms optimization.

death @ step 74 · 50 steps

v31 · novel

Adaptive re-engagement explosion

After distillation auto-disables for 100+ steps, a natural KL drop re-engages a 120-step-stale teacher → grad explosion (142→301) → permanent learning arrest.

death @ step 145 · 5 steps

Results

TT-OPD wins 10 of 18 benchmarks

All models use a Qwen3.5-9B backbone. Base (text) is single-turn log-prob evaluation with no tools; Base+AR adds the multi-turn AgentRunner (135 tools + 828K KB) without RL; GRPO and TT-OPD are RL-trained. Best per row is highlighted.

Category	Benchmark	Basetext	Base+AR	GRPO	TT-OPD
MC QA	MedQA (USMLE)	70.7	78.8	85.5	87.1
	MMLU-Med. (6 sub.)	83.8	60.6	60.1	65.5
	MedMCQA	63.8	55.8	58.0	66.2
Visual QA	VQA-RAD	52.5	63.2	60.7	63.1
	PathVQA	40.5	38.7	41.5	45.3
	SLAKE	79.0	30.6	29.5	32.1
	PMC-VQA	57.9	35.1	34.2	38.9
	VQA-Med-2021	8.6	9.8	10.7	15.2
	Quilt-VQA	25.2	27.8	25.2	30.7
EHR	MIMIC-III	58.5	62.1	61.1	62.7
EHR	eICU	53.2	55.9	55.5	57.1
LFQA	LiveQA	53.2	58.2	57.7	62.5
	MedicationQA	49.5	53.1	55.8	60.9
	HealthSearchQA	39.8	41.9	39.5	45.3
	KQA-Golden	55.7	62.1	65.3	64.1
	KQA-Silver	52.5	61.7	64.9	62.8

Broad competence. TT-OPD is best on 10/18 benchmarks across MC QA, Visual QA, EHR and LFQA — +3.9 pp average over Base+AR.

Agentic overhead. Multi-turn evaluation trades parametric precision for retrieval-augmented reasoning (MMLU 83.8 → 60.6 → 65.5).

GRPO peaks on recall. Vanilla GRPO leads on KQA-Golden/Silver — higher peak training accuracy aids open-ended factual recall.

Stability, not raw accuracy. TT-OPD's win is controlled length (5.7–9.3K tok) and sustained 7.0–7.4 turns throughout training.

Training dynamics: validation accuracy, KL divergence, response length and average turns for TT-OPD vs GRPO. — Training dynamics over 60 steps. TT-OPD (red) controls response length and preserves 7.0–7.4 turns, while GRPO oscillates and EMA-only distillation declines toward single-turn behavior.

Deeper analysis

Does RL internalize tool use — or copy-paste the prompt?

A follow-up study asks whether agentic RL writes tool-use reasoning into the model's weights, or whether the agent is just reading the tool spec from its context window. We answer it with Progressive Spec Withdrawal (PSW) — a curriculum that strips tool definitions out of the prompt during training — and a forensic taxonomy of 31,500+ tool calls.

55

Tool vocabulary collapseunique tools invoked falls 55 → 19 once specs are withdrawn

21%

Reward-driven pruningsearch_pubmed share rises 21.2% → 93.5% — the model keeps only its most reward-efficient tool

0%

Already latentbase, GRPO and PSW all hit the same 86% on MedQA with no tool specs — RL adds no new parametric tool encoding

Accuracy actually rises after specs are removed (58.0% → 61.7%, matching GRPO's 62.0% peak), and PSW reaches 90% with specs — so the curriculum teaches the model to better exploit tool definitions, not to memorize a capability the base model's post-training already had.

A taxonomy of tool hallucination

Across 31,500+ tool calls, failures fall into four distinct modes — each with its own cause and its own signature over training.

SH

Schema Hallucination

A real tool is called with parameters that don't exist in its schema.

< 0.1% · spikes early, fades at convergence

PTI

Phantom Tool Invocation

Entirely fabricated tools (web_search, google_search) that were never defined.

driven by pre-training leakage

SM

Structural Malformation

Broken JSON or unclosed tags that abort the call before it runs.

🐤 the canary — primary stability predictor

STM

Semantic Tool Misuse

Correct syntax, wrong tool for the job — the right call in the wrong place.

causes redundant retrieval loops

↻

RL self-corrects its own vocabulary. When specs are withdrawn, phantom tool names surface around steps 35–100 — then reward pressure prunes them away by step 300. Only tools that produce valid, correct answers survive.

Citation

Cite this work

@article{jeong2026healthcare,
  title   = {Healthcare AI GYM for Medical Agents},
  author  = {Jeong, Minbyul},
  journal = {arXiv preprint arXiv:2605.02943},
  year    = {2026}
}
